Installing the new fan bridge
▶
Install the fan bridge, see "Installing the fan bridge with fan modules (high
performance variant)" on page 93.
▶
Install all fan modules from the fan bridge, see "Installing the new system
fan module" on page
318.
Concluding steps
▶
"Reassembling" on page 68.
▶
"Connecting the power cord" on page 82.
▶
"Switching on the server" on page 83.
8.6 Replacing the fan bridge (low performance
variant)
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
Preliminary steps
▶
"Locating the defective server" on page 47
.
▶
"Shutting down the server" on page 49.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 51.
Removing the defective fan bridge
▶
Remove the fan bridge, see "Removing the fan bridge (low performance
variant)" on page 94.
Fans
320 Upgrade and Maintenance Manual TX2550 M5
