Fujitsu PRIMERGY TX2550 M5 - Installing the Ultraslim ODD in the 4 X 3.5-Inch HDD Extension Box; Ultraslim ODD in 3.5-Inch HDD Extension Box

▶
"Installing the system air duct" on page 68
.
▶
"Reassembling" on page 68.
▶
"Connecting the power cord" on page 82.
▶
"Switching on the server" on page 83.
▶
If applicable, "Reconfiguring the backup software solution" on page 117.
12.6 Ultraslim ODD in 3.5-inch HDD extension
box
12.6.1 Installing the ultraslim ODD in the 4x 3.5-inch
HDD extension box
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: – Phillips PH0 / (+) No. 0 screw driver
– Slotted screw driver (for bending in or out accessible drive
mounting brackets)
Preliminary steps
▶
"Shutting down the server" on page 49
.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 51.
The front cover only needs to be removed in order to remove
accessible drive dummy covers. If the HDD extension box is already
installed in the server and will be removed in order to install an
ultraslim ODD, skip this step.
▶
"Removing the system air duct" on page 67
.
▶
"Removing the PCI air duct" on page 88.
Accessible drives
444 Upgrade and Maintenance Manual TX2550 M5
