If applicable, "Removing the riser module" on page 86.
▶
If applicable, remove the expansion card, see "Removing an expansion
card" on page
358.
▶
Remove the fan bridge, see "Handling the fan bridge" on page 92.
Removing the 4x 3.5-inch HDD extension box
▶
Remove the 4x 3.5-inch HDD extension box, see "Removing the 4x 3.5-
inch HDD extension box" on page 281.
Removing the ultraslim ODD dummy cover
Figure 289: Removing the ultraslim ODD dummy cover
Accessible drives
TX2550 M5 Upgrade and Maintenance Manual 445
