Press on the locking latch on the Ultraslim ODD dummy cover.
▶
Remove the ultraslim ODD dummy cover from the HDD extension box.
CAUTION
▶
Keep the dummy cover for future use.
▶
If you remove the accessible drive again and do not replace it
with a new one, the dummy cover must be reinstalled to comply
with EMC regulations and to satisfy cooling requirements and fire
protection measures.
Installing the ultraslim ODD into the 3.5-inch HDD extension box
Figure 290: Removing the ultraslim ODD latch
▶
Remove the two screws from the locking latch (see circles).
▶
Remove the locking latch.
