7.5.12 Upgrading from 8x to 16x 2.5-inch HDD/SSD
configurations
Upgrade and Repair Unit
(URU)
Hardware: 20 minutes
Software: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
After installing or removing an additional backplane, never forget to
change the system information using the Chassis ID Prom Tool.
Preliminary steps
▶
"Suspending BitLocker functionality" on page 107
.
▶
"Shutting down the server" on page 49.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 51.
▶
Remove all HDD/SSD modules, see "Removing 2.5-inch HDD/SSD
modules" on page 220.
▶
If applicable, remove all dummy modules, see "Removing a 2.5-inch HDD/
SSD dummy module" on page 219.
▶
"Removing the system air duct" on page 67.
▶
Remove the fan bridge, see "Handling the fan bridge" on page 92.
Hard disk drive (HDD) / solid state disk (SSD)
