With one SAS controller
Position Logical drive
number
ServerView RAID Manager display
name
[0] 0 Vendor Product (0)
[1] 1 Vendor Product (1)
[2] 2 Vendor Product (2)
[3] 3 Vendor Product (3)
7.4.3.2 Configuration with up to eight HDD modules
Figure 87: Configuration with up to eight 3.5-inch HDDs
With one SAS controller
Position Logical drive
number
ServerView RAID Manager display
name
[0] 0 Vendor Product (0)
[1] 1 Vendor Product (1)
[2] 2 Vendor Product (2)
[3] 3 Vendor Product (3)
[4] 4 Vendor Product (4)
[5] 5 Vendor Product (5)
Hard disk drive (HDD) / solid state disk (SSD)
174 Upgrade and Maintenance Manual TX2550 M5
