Run the intrusion switch cable through the cable clamps (2) on the HDD
cage and the cable guide (1).
Figure 364: Disconnecting the intrusion switch cable
▶
Connect the intrusion switch cable to the system board (1).
For the cable plan see "Appendix B" on page 589.
Concluding steps
▶
Install the fan bridge, see "Handling the fan bridge" on page 92
.
▶
"Installing the system air duct" on page 68.
▶
"Reassembling" on page 68.
▶
"Connecting the power cord" on page 82.
▶
"Switching on the server" on page 83.
Cables
TX2550 M5 Upgrade and Maintenance Manual 553
