Tools: tool-less
After installing or removing an extension box, never forget to change the
system information using the Chassis ID Prom Tool.
Preliminary steps
▶
"Suspending BitLocker functionality" on page 107
.
▶
"Shutting down the server" on page 49.
▶
"Disconnecting the power cord" on page 50.
▶
Remove all HDD/SSD modules, see "Removing 2.5-inch HDD/SSD
modules" on page 220.
▶
If applicable, remove all dummy modules, see "Removing a 2.5-inch HDD/
SSD dummy module" on page 219.
▶
"Getting access to the component" on page 51.
▶
"Removing the system air duct" on page 67.
▶
Remove the fan bridge, see "Handling the fan bridge" on page 92.
Removing the 8x 2.5-inch HDD/SSD extension box
▶
Remove all cables from the 8x 2.5-inch HDD/SSD extension box backplane.
▶
Disengage the accessible drive locking bar, see "Opening the accessible
drive locking bar" on page 96.
Hard disk drive (HDD) / solid state disk (SSD)
272 Upgrade and Maintenance Manual TX2550 M5
