If applicable, remove the expansion card, see "Removing an expansion
card" on page 358.
Replacing the M.2 SSD
▶
Remove the defective M.2 SSD, see "Removing the M.2 SSD" on page
497.
▶
Install the new M.2 SSD, see
"Installing the M.2 SSD" on page 493.
Concluding steps
▶
If applicable, install the expansion card, see "Installing an expansion card"
on page 346.
▶
"Installing the crossbar" on page 91.
▶
If applicable, install the riser module, see "Installing the riser module" on
page 87.
▶
"Installing the PCI air duct" on page 89.
▶
"Installing the system air duct" on page 68.
▶
"Reassembling" on page 68.
▶
"Connecting the power cord" on page 82.
▶
"Switching on the server" on page 83.
Software configuration
To install the ESXi to the M.2 SSD, see "Software configuration" on
page 495.
System board and components
TX2550 M5 Upgrade and Maintenance Manual 499
