Preliminary steps
▶
"Shutting down the server" on page 49
.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 51.
▶
"Removing the system air duct" on page 67.
▶
"Removing the PCI air duct" on page 88.
▶
If applicable, remove the riser module, see "Removing the riser module" on
page 86.
▶
"Removing the crossbar" on page 90.
▶
If applicable, remove the expansion card, see "Removing an expansion
card" on page 358.
Installing the M.2 SSD
CAUTION
An M.2 SSD in M.2 slot 2 is not recognized, if M.2 slot 1 is free.
▶
The M.2 slot 1 must be equipped first.
Each M.2 SSD needs one hexagon stand-off for fastening. To support
different length of M.2 SSD, several nuts are on the system board
indicating the positions for fastening the M.2 SSD.
If no M.2 SSD has been installed before:
▶
Remove the screw (see orange circles in Figure 319).
If the hexagon stand-off is unscrewed as well, remove the screw from
the hexagon stand-off.
▶
Install the hexagon stand-off on the right position depending on the length of
the M.2 SSD.
System board and components
TX2550 M5 Upgrade and Maintenance Manual 493
