Fujitsu PRIMERGY TX2550 M5 Upgrade And Maintenance Manual

14.2 Basic information 473
14.3 CMOS battery 474
14.3.1 Replacing the CMOS battery 474
14.4 Trusted Platform Module (TPM) 476
14.4.1 TPM kit 476
14.4.2 Installing the TPM 476
14.4.3 Removing the TPM 480
14.4.4 Replacing the TPM 485
14.5 iRMC microSD card 487
14.5.1 Note for embedded Lifecycle Management (eLCM) 487
14.5.2 Installing the iRMC microSD card 487
14.5.3 Removing the iRMC microSD card 489
14.5.4 Replacing the iRMC microSD card 490
14.6 M.2 SSD 491
14.6.1 Slots and bolts for M.2 SSDs 491
14.6.2 Installing an M.2 SSD 492
14.6.3 Removing an M.2 SSD 496
14.6.4 Replacing the M.2 SSD 498
14.7 Dual microSD 64GB Enterprise 500
14.7.1 Position of the Dual microSD 64GB Enterprise 500
14.7.2 Installing the Dual microSD 64GB Enterprise 500
14.7.3 Removing the Dual microSD 64GB Enterprise 505
14.7.4 Replacing the Dual microSD 64GB Enterprise 508
14.7.5 Replacing the microSD card 510
14.8 System board 512
14.8.1 Replacing the system board 512
15 Serial interface 523
15.1 Safety notes 523
15.2 Installing the serial interface 523
15.3 Removing the serial interface 526
Content
TX2550 M5 Upgrade and Maintenance Manual

Fujitsu PRIMERGY TX2550 M5 Specifications

General

Tcase	78 °C
Scalability	2S
Processor cache	13.75 MB
Processor cores	10
Processor model	4210
System bus rate	- GT/s
Processor socket	LGA 3647 (Socket P)
Processor threads	20
Processor codename	Cascade Lake
Execute Disable Bit	Yes
Processor frequency	2.2 GHz
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	76.0 x 56.5 mm
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
Supported instruction sets	AVX-512
Thermal Design Power (TDP)	85 W
Number of processors installed	1
Maximum number of PCI Express lanes	48
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2400 MHz
Maximum internal memory supported by processor	1024 GB
Memory slots	12
Internal memory	16 GB
Memory clock speed	2933 MHz
Maximum internal memory	1500 GB
HDD size	2.5 \
RAID levels	0, 1, 5, 6, 10, 50, 60
HDD interface	Serial ATA, Serial Attached SCSI (SAS)
Optical drive type	No
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs supported	8
Chassis type	Tower
Product color	Black, Red
Operating system installed	-
Compatible operating systems	Microsoft Hyper-V Server 2016 Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2016 Standard Microsoft Windows Server 2016 Essentials Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 R2 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Storage Server 2012 R2 Standard VMware vSphere 6.5 VMware vSphere 6.0 SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7 Red Hat Enterprise Linux
Power supply	800 W
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 85 %
Certification	CB, RoHS, WEEE, GS, CE, CSAc/us, FCC Class A, VCCI, KN32, KN35, CCC, C-Tick
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
PCI Express slots version	3.0
On-board graphics card model	Not available
Processor ARK ID	193384

Weight and Dimensions

Depth	177 mm
Width	448 mm
Height	736 mm
