For the cable plan, see "Appendix B" on page 589.
Concluding steps
▶
Install the fan bridge, see "Handling the fan bridge" on page 92
.
▶
"Installing the system air duct" on page 68.
▶
Install HDD modules or HDD dummy modules into all HDD bays, see
"Installing a 3.5-inch HDD module" on page 178 and "Installing a 3.5-inch
dummy module" on page 181.
For more information on HDD mounting order, see "3.5-inch HDD
configurations" on page 172.
▶
"Reassembling" on page
68.
▶
"Connecting the power cord" on page
82.
▶
"Switching on the server" on page 83.
▶
Update the system information of your server using the Chassis ID Prom
Tool, see "Using the Chassis ID Prom Tool" on page 136. Select the
corresponding system name.
▶
"Resuming BitLocker functionality" on page 130.
Hard disk drive (HDD) / solid state disk (SSD)
TX2550 M5 Upgrade and Maintenance Manual 201
