Figure 110: Example: three backplanes - floorstand model
1 SAS backplane 1 in HDD cage 1 (basic
configuration)
2 SAS backplane 2 in optional HDD cage
2
3
SAS backplane 3 in optional 8x 2.5-
inch HDD extension box
This numbering is based on "Configuration with up to 24 HDDs/SSDs
with HDD extension box" on page
21
1.
Hard disk drive (HDD) / solid state disk (SSD)
TX2550 M5 Upgrade and Maintenance Manual 203
