Up to two FBUs or one FBU and one Dual microSD 64GB Enterprise can be
installed in the system.
Different FBUs and FBU cables are available, depending on the RAID
controller.
Figure 244: Example FBU for PRAID EP4x0i
Figure 245: Example FBU345 for PRAID EP5x0i
Expansion cards and backup units
TX2550 M5 Upgrade and Maintenance Manual 379
