Figure 278: Accessible drives mounting order (rack model)
1 Bay 1
2
Bay 2
3
Bay 3
Figure 279: Accessible drives mounting order (floorstand model)
1 Bay 1
2
Bay 2
3
Bay 3
Accessible drives
430 Upgrade and Maintenance Manual TX2550 M5
