If applicable, remove the riser module, see "Removing the riser module" on
page 86.
▶
"Removing the crossbar" on page 90
.
▶
Remove the fan bridge, see "Handling the fan bridge" on page 92.
Removing the defective TPM
▶
Remove the TPM, see "Removing the TPM" on page 480.
▶
Leave the TPM spacer on the system board when removing the defective
TPM.
Installing the new TPM
The TPM spacer is already present on the system board.
▶
Install the TPM, see "Installing the TPM" on page 476.
Concluding steps
▶
Install the fan bridge, see "Handling the fan bridge" on page
92.
▶
"Installing the crossbar" on page 91.
▶
If applicable, install the riser module, see "Installing the riser module" on
page 87.
▶
"Installing the PCI air duct" on page 89.
▶
"Installing the system air duct" on page 68.
▶
"Reassembling" on page 68.
▶
"Connecting the power cord" on page 82.
▶
"Switching on the server" on page 83.
▶
"Resuming BitLocker functionality" on page 130.
You can find information on configuring the TPM in the corresponding
BIOS Setup Utility reference manual.
System board and components
