Tools: Replacing the system board:
Phillips PH2 / (+) No. 2 screw driver
hexagon screw driver 5 mm
Magnifying glass for inspecting CPU socket springs
(recommended)
Replacing the TPM:
Bit screw driver
Flat nose pliers
TPM bit insert
(*)
Thin slotted screw driver (2 x 0.4 mm)
(*)
(*)
For Japan:
Dedicated TPM screw driver (CWZ8291A)
TPM module fixing tool (S26361-F3552-L909)
If an OCP module is installed:
Phillips PH1 / (+) No. 1 screw driver
Note on TPM
The system board can be equipped with an optional TPM. This module
enables third party programs to store key information (e.
g. drive
encryption using Windows Bitlocker Drive Encryption).
If the customer is using TPM functionality
, the TPM has to be removed
from the defective system board and connected to the new system
board. For more information, see "Replacing the TPM" on page 485.
The TPM has to be enabled in the system BIOS.
System board and components
TX2550 M5 Upgrade and Maintenance Manual 513
