GEDRAFT LOGIQ P9/P7

IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL

Chapter 8 - Replacement Procedures 8-15

8-3-5-2-1-7 Connectivity - Recording the Print Key Assignments

1) From the touch panel, select Utility -> Connectivity -> Buttons.

Figure 8-7 Connectivity - Recording the Print Key Assignments

2) Record all settings in Table 8-11.

Table 8-11 Record settings from Button screen

Parameter Format Image Frames Compression

Compression

Quality

Printflow View

Print1

Print2

Print3

Print4

Print5

Print6

PrintScreen
