4.1.6.3 Outputs
Output Name Output Description Choices
AnalogOutput01 -
AnalogOutput02
First of two analog outputs - board point, Point edit Output REAL
Output_MA Output current, mA selection. Unused, 0-20 mA
OutputState State of the outputs when offline. When the YAIC loses
communication with the controller, this parameter determines
how it drives the outputs:
PwrDownMode - Open the output relay and drive outputs to
zero current
HoldLastVal - Hold the last value received from the controller
Output_Value - Go to the configured output value set by the
parameter Output_Value
PwrDownMode
HoldLastVal
Output_Value
Output_Value Pre-determined value for the outputs -3.4082 e + 038 to 3.4028 e + 038
Low_MA Output mA at low value 0 to 200 mA
Low_Value Output in Engineering Units at Low_MA -3.4082 e + 038 to 3.4028 e + 038
High_MA Output mA at high value 0 to 200 mA
High_Value Output value in Engineering Units at High_MA -3.4082 e + 038 to 3.4028 e + 038
TMR_Suicide Enables suicide for faulty output current, TMR only Enable, Disable
TMR_SuicLimit Suicide threshold (Load sharing margin) for TMR operation, in
mA
0 to 200 mA
D/A_ErrLimit Difference between D/A reference and feedback, in % for
suicide, TMR only
0 to 200 %
Dither_Ampl Dither % current of Scaled Output mA 0 to 10
Dither_Freq Dither rate in Hertz Unused, 12.5hz, 25hz, 33.33hz, 50hz, 100hz
YAIC Analog I/O Modules GEH-6855_Vol_II System Guide 99
