GE Mark VIeS - Power Distribution Module and Daughterboard Part Numbers

Module Part Numbers (continued)
I/O Pack/Part
Number
Associated Base
Assembly/Accessory
Description
Replacement Part within
Module
Notes
IS420YVIBS1B
N/A
Vibration I/O pack
Board: IS400BPPCS1A
Board: IS400BBAAS1A
IS410TVBAS2B
Simplex or TMR, 8 Vib/Prox, 3
Pos, 2 Key/Pos, 7" T-type TB, with
cover and TB blocks
Board: IS400TVBAS2B
Cover: 151X1202YE08PP14BL
24 pt TB (1-24): 173C9123BB
003
24 pt TB (25-48): 173C9123BB
004
IS420PSCAH1B
N/A
Serial Communication / Modbus
Master I/O pack
Board: IS400BPPCS1A
Board: IS400BSCAH3A
IS410SSCAH2A
Simplex, 6 channel Serial Comm
Termination Board , 4" S-type TB,
with cover and TB plugs
Board: IS400SSCAH2A
Cover: 151X1202YE04PP01BL
48 pt TB: 64G6940-224L
Power Distribution Module and Daughterboard Part Numbers
I/O Pack/Part
Number
Associated Base
Assembly/Accessory
Description
Replacement Part within
Module
Notes
IS420PPDAH1B
N/A
JPDG / JPDS Power Supply
Diagnostics I/O pack
Board: IS400BPPCH1A
Board: IS400BPDAH1A
IS410JPDSG1A
28 V Control Power Distribution,
with diagnostics I/O pack, with
cover
Board: IS400JPDSG1A
Cover: 151X1202YE12PP02BL
IS410JPDGH1A
28 V Dual Control and 24 V (or 48
V) Wetting Power Distribution,
with diagnostics, with cover
Board: IS400JPDGH1A
Cover: 151X1202YE12PP02BL
10 A fuse: 64G5002-001
15 A fuse: 64G5003-001
N/A
IS410JPDDG2A
24 or 48 V dc wetting distribution
via 6 switch branches, 5 x 20 mm
fuse holder, with cover
Board: IS400JPDDG2A
Cover: 151X1202YE12PP04BL
Fuse: any 20.0 × 5.0 mm (0.79 ×
0.20 in)
IS410JPDDG3A
24 or 48 V dc wetting distribution
via 6 switch branches, 1.25 x 0.2
5in fuse holder, with cover
Board: IS400JPDDG3A
Cover: 151X1202YE12PP04BL
Fuse: any 31.75 × 6.35 mm (1.25
× 0.25 in)
IS410JPDEG1A
TMR Wetting Power System /
Distribution module (24 or 48 V
dc), with cover
Board: IS400JPDEG1A
Cover: 151X1202YE12PP01BL
7 A fuse: 64G5001-001
15 A fuse: 64G5003-001
IS410JPDHG1A
Control Power Fanout
Distribution, with cover
Board: IS400JPDHG1A
Cover: 151X1202YE12PP03BL
