GE Mark VIeS - Customer Terminal Points

8.5.2.8 Customer Terminal Points
Channel
Signal Name
Pin #
Description
GAP1_VIB1
N24V01 1
-24 V power supply output for channel #1
PR01H 2
Input #1 signal high side to I/O pack and buffered output
PR01L 3
Input #1 signal low side to I/O pack and buffered output
GAP2_VIB2
N24V02 4
-24 V power supply output for channel #2
PR02H 5
Input #2 signal high side to I/O pack and buffered output
PR03L 6
Input #2 signal low side to I/O pack and buffered output
GAP3_VIB3
N24V03 7
-24 V power supply output for channel #3
PR03H 8
Input #3 signal high side to I/O pack and buffered output
PR03L 9
Input #3 signal low side to I/O pack and buffered output
GAP4_VIB4
N24V04 10
-24 V power supply output for channel #4
PR04H 11
Input #4 signal high side to I/O pack and buffered output
PR04L 12
Input #4 signal low side to I/O pack and buffered output
GAP5_VIB5
N24V05 13
-24 V power supply output for channel #5
PR05H 14
Input #5 signal high side to I/O pack and buffered output
PR05L 15
Input #5 signal low side to I/O pack and buffered output
GAP6_VIB6
N24V06 16
-24 V power supply output for channel #6
PR06H 17
Input #6 signal high side to I/O pack and buffered output
PR06L 18
Input #6 signal low side to I/O pack and buffered output
GAP7_VIB7
N24V07 19
-24 V power supply output for channel #7
PR07H 20
Input #7 signal high side to I/O pack and buffered output
PR07L 21
Input #7 signal low side to I/O pack and buffered output
GAP8_VIB8
N24V08 22
-24 V power supply output for channel #8
PR08H 23
Input #8 signal high side to I/O pack and buffered output
PR08L 24
Input #8 signal low side to I/O pack and buffered output
GAP9_POS1
N24V09 25
-24 V power supply output for channel #9
PR09H 26
Input #9 signal high side to I/O pack and buffered output
PR09L 27
Input #9 signal low side to I/O pack and buffered output
GAP10_POS2
N24V10 28
-24 V power supply output for channel #10
PR10H 29
Input #10 signal high side to I/O pack and buffered output
PR10L 30
Input #10 signal low side to I/O pack and buffered output
GAP11_POS3
N24V11 31
-24 V power supply output for channel #11
PR11H 32
Input #11 signal high side to I/O pack and buffered output
PR11L 33
Input #11 signal low side to I/O pack and buffered output
GAP12_KPH2
N24V12 34
-24 V power supply output for channel #12
PR12H 35
Input #12 signal high side to I/O pack and buffered output
PR12L 36
Input #12 signal low side to I/O pack and buffered output
GAP13_KPH1
N24V13 37
-24 V power supply output for channel #13
PR13H 38
Input #13 signal high side to I/O pack and buffered output
PR13L 39
Input #13 signal low side to I/O pack and buffered output
GAP_KP_BN1
N24V14 40
-24 V power supply output for channel #14
PR14H 41
Input #14 signal high side to buffered output ONLY
PR14L 42
Input #14 signal low side to buffered output ONLY
43 - 48 No connections
