4.4 STAIS2A Simplex Analog Input
The Simplex Analog Input (STAI) terminal board is a compact analog input terminal board that accepts 10 analog inputs and
two analog outputs, and connects to the pack. The 10 analog inputs accommodate two-wire, three-wire, four-wire, or
externally powered transmitters. The two analog outputs are 0-20 mA. High-density Euro style box terminal blocks are used.
An on-board ID chip identifies the board to the pack for system diagnostic purposes.
Compatibility
Board Revision
Mark VIeS YAIC Comments
STAIS2A Yes Plug in terminals, IEC 61508 safety certified with YAIC
YAIC Analog I/O Modules GEH-6855_Vol_II System Guide 113
Public Information
