7.2 Specifications
YUAA Specifications
Item
Specification
Number of Channels
16 channels, with groups of three terminals per channel
Supported Redundancy Simplex
Shared IONet
Supported
Required ControlST and YUAA
Versions
ControlST Software Suite V07.02.00C or later
YUAA firmware V05.05.00 or later
Auto-Reconfiguration Supported
RJ-45 Ethernet Ports
Supports dual Ethernet (IONet) networks
Fastest Frame Rate Supported
10 ms
Supported I/O Types
• Thermocouple
• RTD
• 4–20 mA current input with HART option
• ± 5 V or ± 10 V input
• 0–20 mA current output with HART option
• Digital inputs and outputs
• Pulse accumulators
Incoming Control Power 28 V dc source is required
Incoming Power Consumption
Power consumption is based on 8.1 watts quiescent plus power per channel modes as follows:
• TC, 5V, 10V, externally wetted discrete inputs, pulse accumulator inputs, or RTD modes = 0.02 watts
per channel
• External fed mA input and internally wetted discrete inputs = 0.04 watts per channel
• Internal fed mA input or mA output = 0.68 watts per channel or less, depending on external loop
resistance
Power Output to Field Device
From SUAA screws PWR_RTN, supply is a maximum 2 V less than the incoming control power to the
YUAA I/O pack
I/O Pack Internal Current Limiter
2.5 A to limit impact to supply if a short circuit failure should occur
I/O Pack Hot Swap Replacement Supported
28 V dc Power Connector
Phoenix
®
contact part number MC 1.5/S-STF-3.81
Rating for Ambient Temperature on
Module Exterior During Operation
-40 to 70°C (-40 to 158 °F)
Storage Temperature Rating -40 to 85°C (-40 to 185 °F)
Relative Humidity Required 5 to 95% non-condensing
Lightning Strike Protection
UL61010-1
Operating Vibration
IEC/EN 60068-2-6
Flammability Rating
UL94V-2
I/O Pack Casing Protection Against
Intrusion
Ingress Protection Code: IP20 per EN 60529
General I/O Pack Specifications
Refer to GEH-6855_Vol_I for technical regulations and standards that apply to all of the Mark VIeS
Functional Safety System equipment
YUAA Module Dimensions
6.6 in L x 3.4 in W x 4.3 in H (with I/O pack attached)
Average panel area/channel is equal to small S card footprint per group of 16 channels
Mode Miswired Tolerance
Refer to the ToolboxST Configuration Modes section for details regarding YUAA resistance to damage
when incorrectly wired or configured.
172 GEH-6855_Vol_II GEH-6855_Vol_II Mark VIeS Functional Safety Systems Volume II
