2.1.4 UCSC Mounting and Installation Requirements
2.1.4.1 UCSC Mounting Requirements
The following are requirements for mounting the UCSC controller:
• Directly mount the UCSC to the mounting base using the two mounting screws.
• Vertical mount with unobstructed air flow through fins.
• Leave a minimal 100 mm (3.94 in) air gap above and below the UCSC.
• Parallel mount UCSC to UCSC requires a minimal 50 mm (1.97 in) spacing to achieve full temperature rating.
• The operating temperature envelope is 25 mm (0.98 in) from any point on UCSC.
