GE Mark VIeS - 24;48 V DC Wetting Power Distribution

24/48 V DC Wetting Power Distribution
Serial
#
Connector
Name
Function Description — Pin numbers Fuses
†
1 JPS1 24/48 V dc input 1 Pin 1–4 — Return,
Pin 6–9 — positive
2 JPS2 24/48 V dc input 2 Pin 1–4 Return,
Pin 6–9 — positive
3 JFA 24/48 V dc output 1 Pin 2 dc return, pin 1 positive Pin 1 goes through
FU10.
Pin 2 goes through
FU11.
4 JFB 24/48 V dc output 2 Pin 2 dc return, pin 1 positive Pin 1 goes through
FU12.
Pin 2 goes through
FU13.
5
JFC 24/48 V dc output 3 Pin 2 dc return, pin 1 positive Pin 1 goes through
FU14.
Pin 2 goes through
FU15.
6 JFD 24/48 V dc output 4 Pin 2 dc return, pin 1 positive Pin 1 goes through
FU16.
Pin 2 goes through
FU17.
7 JFE 24/48 V dc output 5 Pin 2 dc return, pin 1 positive Pin 1 goes through
FU18.
Pin 2 goes through
FU19.
8 JFF 24/48 V dc output 6 Pin 2 dc return, pin 1 positive Pin 1 goes through
FU20.
Pin 2 goes through
FU21.
9 JFG 24/48 V dc output 7 Pin 2 dc return, pin 1 positive Pin 1 goes through
FU22.
Pin 2 goes through
FU23.
10 P4 24/48 V dc power supply status
inputs
Pin 1 is 10 V output for supply 1
status contact
Pin 2 is 10 V output for supply 2
status contact
Pin 3 is return for supply 1 status
contact
Pin 4 is return for supply 2 status
contact
11 TP3 24/48 V dc Test point Positive
12 TP4 24/48 V dc Test point Return
†
These are 15 A replaceable fuses, however the actual current drawn through each of these branches must not be more than
10 A.
