GE Mark VIeS - Gap 9-11

8.3.4.10 Gap 9-11
[ ] = defaults
Name Direction Data
Type
Description VIB_Type2 Scale Scale_Off TMR_
DiffLimit
GAP9_POS1 AnalogInput REAL Average Air Gap,DC
component of input#9
Sensor Type, group
2
[Unused],
PosProx
Volts/mil
or
Volts/ips
[0.2]
0 to 2
Scale offset
for Prox
position
only, in mils
[0]
0 to 90
Difference
Limit for Voted
TMR Inputs in
Volts or Mils
[2]
-100 to 100
GAP10_POS2 AnalogInput REAL Average Air Gap,DC
component of input#10
GAP11_POS3 AnalogInput REAL Average Air Gap,DC
component of input#11
GnBiasOvride Snsr_Offset Gain SysLim1Enabl SysLim1Latch SysLim1Type SysLimit1
Gain Bias
Override
[Disable], Enable
Amount of bias
voltage (dc) to
remove from
input signal used
to max. A/Ds
signal range
used only when
GnBiasOvride is
enabled
[10]
±13.5
Resolution of
input signal (net
gain unchanged),
select based on
expected range,
use only if
GnBiasOvride is
enabled
[1x], 2x, 4x, 8x
Enable System
Limit 1
[Disable], Enable
Latch the alarm
[Latch], NotLatch
System Limit 1
Check Type
[ >= ] , <=
System Limit 1 –
GAP in negative
volts (Velomitor)
or positive mils
(Prox)
[90]
-100 to 100
SysLim2Enabl SysLim2Latch SysLim2Type SysLimit2
Enable System Limit 2
[Disable], Enable
Latch the alarm
[Latch], NotLatch
System Limit 2 Check Type
[ >= ] , <=
System Limit 2 – GAP in
negative volts (Velomitor) or
positive mils (Prox)
[10]
-100 to 100
