Environment
Item
Phoenix Specification
Operating Temperature
-25°C to +70°C (-13 to 158 °F) Free Convection (no fans), de-rate 2.5%/K above 60°C
(140 °F)
Storage Temperature (non-operating) -40 to 85°C (-40 to 185 °F)
Relative Humidity 95% ( at 25°C [77 °F] non-condensing)
Environmental Compatibility
Pollution Degree 2 according to EN 50178
Climatic Class 3K3 according to EN 60721
Coated Units: G3 Harsh Environment, according to ANSI/ISA 71.04
Housing Steel sheet, zinc-plated, closed
Degree of Protection
IP20
Protection class
Power Supply: Ι, with PE connection
FET-OR Module: III
Vibration and Shock
Item
Specification
Vibration
< 15 Hz, amplitude ±2.5 mm, according to IEC 60068-2-6
15 Hz - 150 Hz, 2.3g, 90 minutes
Shock
30g in all directions, per IEC 60068-2-27
Seismic Universal Building Code (UBC) Not applicable at the power supply (component) level
Safety Standards, Approvals, and Marks
Item
Specification
Electrical Safety of Industrial Equipment
EN 60204
Electrical Safety of Information Technology
Equipment
EN 60950-1/VDE 0805 (SELV)
SELV
IEC 60950-1 (SELV) and EN 60204 (PELV)
cULus
UL 508; ANSI/ISA 12.12.01 (Class I, Division 2, Groups A, B, C, D; T4)
cURus UL 60950
ATEX
EN 60079-0, EN 60079-15 (II 3 G Ex nA IIC T4 Gc)
Refer to the table Phoenix Power Supplies and FET-OR Modules, Note 4.
IECEx
IEC 60079-0, IEC 60079-15 (Ex nA IIC T4 Gc)
Refer to the table Phoenix Power Supplies and FET-OR Modules, Note 4.
CE
EN 61000-6-2, EN 61000-6-3
Diagnostics
LED Function
Power Supply
DC OK – Active output
18 – 24 V dc, 20 mA
DC OK – Floating NO contact
30 V ac/dc, 1 A
POWER BOOST – Active output
18 – 24 V dc, 20 mA
FET-OR Module
Redundancy OK – Floating NO contact
30 V ac/dc, 100 mA
Automatic Current Balancing (ACB) OK – Floating NO contact
30 V ac/dc, 100 mA
PDM Power Distribution Modules GEH-6855_Vol_II System Guide 403
Public Information
