7.12.3 Voltage Inputs
Voltage Inputs InputType Low_Input Low_Value High_Input High_Value InputFilter
Description Type of
Analog Input
Input Volts at
Low Value
Low Input in
Engineering Units
Input Volts at
High Value
High Input in
Engineering
Units
Filter
Bandwidth in
Hz
Choices
{defaults}
+/-10volt
{+/-5volt}
{-5} {0} {5} {100} 0.75, 1.5, 3, 6,
12, {Unused}
Low_Input, Low_Value, High_Input, High_Value settings are used by the I/O pack firmware to define the linear relationship
between Volts and customer-defined engineering units. The I/O Point value will be in Engineering units. Engineering units are
specific to the field device being used.
7.12.4 RTDs
RTDType
Compatible Type
Notes
MINCO_NA N 120 RTDType selects the type of RTD device connected to the input. The Ohms type returns a
value of resistance, with the TempUnits parameter ignored.
The temperature units parameter, TempUnits, can be either Fahrenheit or Celsius, and is
set from the Parameters tab.
MINCO_PA PT100 PURE
MINCO_PB PT100 USIND
{MINCO_PD} PT100 DIN
MINCO_PIA
MINCO_PK PT 200
MINCO_PN
MINCO_CA CU10
Ohms
PT100_SAMA SAMA 100
7.12.5 Thermocouples
ThermCplType ReportOpenTC
Notes
B
E
J
K
{mV}
N
R
S
T
{Fail_Cold}
Fail_Hot
ThermCplType selects the type of TC device connected to the input. The mV type shall
only return a value of millivolts, the Units parameter shall be ignored for this type, and no
cold junction compensation shall be performed.
ReportOpenTC is a Fail_Hot/Fail_Cold configuration to control the reported TC value when
an open circuit occurs. On open circuit detection the I/O pack will report the calculated
value at -40 mV (Open TC Threshold) when Fail_Cold in enabled, and will report 3632 ºF
(2000 ºC) when Fail_Hot is enabled.
The temperature units parameter, TempUnits, can be either Fahrenheit or Celsius, and is
set from the Parameters tab.
YUAA Universal I/O Modules GEH-6855_Vol_II System Guide 205
