Current Outputs (continued)
Hart_Enable
‡
Hart_CtrVars Hart_ExStatus Hart_MfgID
Hart_DevType Hart_DevID
Enable Hart protocol on
this channel
Number of control vars to
read from Hart device
Set to zero if not used.
Number of extended status
bytes to read from Hart
device
Set to zero if not used.
Hart Field Device -
Manufacture ID
Note: For HART7 field
devices, this is the upper
byte of Expanded Device
Type
A diagnostic alarm is sent
if the field device ID differs
from this value and the
value is non-zero. This
value can be uploaded
from the YUAA if the field
device is connected.
(Right-click on device
name and select Update
HART IDS)
Hart Field Device - Device
Type
Note: For HART7 field
devices, this is lower byte
of Expanded Device Type
Hart Field Device - Device
ID
{Disable}
Enable
{0}
0-5
{0}
0-26
{0}
0-255
{0}
0-255
{0}
0-116777215
Attention
‡
The first time any channel 1–8 is enabled, the I/O pack will require a reboot. The first time any channel 9–16 is enabled, the I/O
pack will require a reboot.
The first time all channel 1–8 are disabled, the I/O pack will require a reboot. The first time all channel 9–16 are disabled, the
I/O pack will require a reboot.
204 GEH-6855_Vol_II GEH-6855_Vol_II Mark VIeS Functional Safety Systems Volume II
