YUAA DIN-rail Installation and Removal
For installation, engage the rear DIN-rail
guide over the edge of the module and rotate
downward to snap the module onto the rail.
First time installation may require extra force
to engage the rail locking
For removal, Use a large flat bladed
screwdriver to pull the rail clip away from the
rail. Rotate the module back and slide away
from the rail.
178 GEH-6855_Vol_II GEH-6855_Vol_II Mark VIeS Functional Safety Systems Volume II
