6.1.4 Specifications
Item
YDOA Specification
Number of Relay Channels 12 relays (different types depending on the terminal board)
Relay and Coil Monitoring
12 relay/coil monitors, 3–fuse status feedbacks are multiplexed to read status from
six fuses
I/O Pack Response Time From Ethernet command to output is approximately 6 ms
SOE Reporting
Each relay can be configured to report operation in the Sequence of Events (SOE)
record
Size
8.26 high x 4.19 wide x 12.1 deep cm
(3.25 x 1.65 x 4.78 in)
Technology
Surface-mount
Ambient Rating for Enclosure Design -40 to 70°C (-40 to 158 °F)
Note For further details, refer to the Mark VIeS Functional Safety Relay Contact Output Module Summary Sheet
(GEI-100863).
YDOA Discrete Output Modules GEH-6855_Vol_II System Guide 135
Public Information
