GE Mark VIeS - TRLYS#F Specifications; Derating Voted Relay Contact Output Diagram

6.7.4 TRLYS#F Specifications
Item
TRLYS#F Specification
Number of Output Relay Channels
S1F: 12 NO contacts
S2F: 12 NC contacts
Rated Voltage on Relays
Nominal 100/125 V dc or 24 V dc
Nominal 115 V ac
Max Load Current
0.5/0.3 A resistive for 100/125 V dc operation
5.0 A resistive for 24 V dc operation
5.0 A resistive for 115 V ac
Max Response Time On
25 ms
Contact Life
Electrical operations: 100,000
Fault Detection
Coil Voltage disagreement with command
Unplugged cable or loss of communication with I/O pack; relays de-energize if
communication with associated I/O pack is lost
Size
17.8 cm wide x 33.02 cm high (7.0 in x 13.0 in)
Operating Temperature Refer to the following figure, Derating Voted Relay Contact Output Diagram.
The following figure illustrates derating the voted contact output channel quantity based on the maximum applied ambient.
12
10
8
4
6
2
Voted Relay Contacts (Kn)
-40 -20 0 20 40 60 80
12
10
8
4
6
2
-40 -20 0 20 40 60 80
TRLY_#F
Voted Relay Contacts (Kn)
TRLY_#F
Maximum number of
Kn connecting to odd
or even outputs
Not applicable with
ambient above
60ºC (140 ºF)
60ºC (140 ºF)
ambient maximum
70ºC (158 ºF)
ambient maximum
12
10
8
4
6
2
-40 -20 0 20 40 60 80
6
5
4
2
3
1
-40 . . . . . 7055 60 80
TRLY_#F with WDPF TRLY_#F with WDPF
45ºC (113 ºF)
ambient maximum
7
8
70ºC (158 ºF)
ambient
maximum
Not applicable with
ambient above 55ºC (131 ºF)
Maximum number of Kn
Odd outputs - K1, 3, 5, 7, 9, 11
Even outputs - K2, 4, 6, 8,10, 12
Voted Relay Contacts (Kn)
Voted Relay Contacts (Kn)
5 outputs - K1, 6, 7, 12, (K3 or K10)
4 outputs - K1, 6, 7, 12
Temperature ºC Temperature ºC
Temperature ºC Temperature ºC
Derating Voted Relay Contact Output Diagram
