10.2.8.5 JPDG Fuse/Dry Contacts
Variable Description Direction Type
FU1_Stat Main JPDG - FU1 fuse status (connector J1) Input BOOL
FU2_Stat Main JPDG - FU2 fuse status (connector J1) Input BOOL
FU3_Stat Main JPDG - FU3 fuse status (connector J2) Input BOOL
FU4_Stat Main JPDG - FU4 fuse status (connector J2) Input BOOL
FU5_Stat Main JPDG - FU5 fuse status (connector J3) Input BOOL
FU6_Stat Main JPDG - FU6 fuse status (connector J3) Input BOOL
FU7_Stat Main JPDG - FU7 fuse status (connector J4) Input BOOL
FU8_Stat Main JPDG - FU8 fuse status (connector J4) Input BOOL
DryCntStat_1 Main JPDG - P28 V bus dry contact - 1 status Input BOOL
DryCntStat_2 Main JPDG - P28 V bus dry contact - 2 status Input BOOL
FU10_FU11_Stat Main JPDG - FU10/FU11 fuse status (connector JFA) Input BOOL
FU12_FU13_Stat Main JPDG - FU12/FU13 fuse status (connector JFB) Input BOOL
FU14_FU15_Stat Main JPDG - FU14/FU15 fuse status (connector JFC) Input BOOL
FU16_FU17_Stat Main JPDG - FU16/FU17 fuse status (connector JFD) Input BOOL
FU18_FU19_Stat Main JPDG - FU18/FU19 fuse Status (connector JFE) Input BOOL
FU20_FU21_Stat Main JPDG - FU20/FU21 fuse status (connector JFF) Input BOOL
FU22_FU23_Stat Main JPDG - FU22/FU23 fuse status (connector JFG) Input BOOL
DryCntStat_3 Main JPDG - P24/48 V bus dry contact - 1 status Input BOOL
DryCntStat_4 Main JPDG - P24/48 V dry contact - 2 status Input BOOL
10.2.8.6 JPDE Inputs
Parameter Description
Choices
InputDiagEnab Input diagnostic enable Enable, Disable
DC_24v_Trig_Volt DC 24/48 V fault trigger voltage 10 to 60
Variable**
Description Direction Type
DC_24VFdbkMag_x JPDE x - DC 24/48 V magnitude AnalogInput REAL
** x = 1, 2
10.2.8.7 JPDE Gnd Volts
Parameter Description
Choices
Gnd_Mag_Trig_Volt Ground magnitude fault trigger voltage 1 to 30
Variable**
Description Direction Type
DC_24VGnd_FdbkMag_
x
JPDE x - ground feedback magnitude AnalogInput REAL
** x = 1, 2
PDM Power Distribution Modules GEH-6855_Vol_II System Guide 317
