6 YDOA Discrete Output Modules
6.1 Mark VIeS YDOA Discrete Output Pack
The Discrete Output (IS420YDOAS1B) I/O pack provides the electrical interface
between one or two I/O Ethernet networks and a discrete output terminal board. The
pack contains a common processor board and an acquisition board specific to the
discrete output function. The YDOA is capable of controlling up to 12 relays and
accepts terminal board specific feedback. Electromagnetic relays (with types TRLYS1B,
D, and F terminal boards) are available. Input to the pack is through dual RJ-45 Ethernet
connectors and a three-pin power input. Output is through a DC-37 pin connector that
connects directly with the associated terminal board connector. Visual diagnostics are
provided through indicator LEDs.
TRLY Relay Output
Terminal Board
(5 types)
YDOA Discrete Output
Relay Outputs
(6 or 12)
Processor boardApplication board
One YDOA pack for Simplex
Single or dual
Ethernet cables
ENET1
ENET2
External 28 V dc
power supply
ENET1
ENET2
ENET1
ENET2
28 V dc
28 V dc
Three YDOA packs for TMR
and Dual control .
YDOA Discrete Output Modules GEH-6855_Vol_II System Guide 131
Public Information
