6.2 Making Auto Print Settings
92
From the Status screen, select the [Num Calc] sheet and set the [Print Calc
Result] item to [On].
See: "10.5 Printing Numerical Calculation Results" ( p.184)
• When both Auto Print and Auto Save are enabled, Auto Save is executed first.
• However, when the Roll Mode function (default setting: Auto) is used with the
Memory function, Auto Print has priority.
• If A/B cursor is On during manual printing after acquiring waveform data, the
range will be printed.
Timebase (Time/div) Measurement conditions Printing
Up to 200 ms/div Memory Function or Recorder
Function
Recording length: Other than Con-
tinuous (Cont.)
Data are acquired for
the recording length
and then printed auto-
matically
Recorder Function
Recording length: Continuous
(Cont.)
Printing disabled
More than 500 ms/
div
Memory Function
Roll Mode: On
Printing is carried out
in real time along with
recording.
Recorder Function
Simultaneous printing of numerical calculation results
