Appendix 2 Reference
A2
Refer to the following table for information about the waveform file sizes.
References
References of the file size _______________________________________
Appendix 2 Reference
Appendix 2.1 Waveform File Sizes
File Type Function Sizes Calculation method
MEM File Memory Function ( p.A2) ( p.A4)
REC File Recorder Function ( p.A2) ( p.A4)
FFT File FFT Function ( p.A3) ( p.A4)
XYC File X-Y Recorder Function ( p.A3) ( p.A4)
CSV (Text) File
Memory Function ( p.A3) ( p.A4)
Recorder Function (
 p.A3) ( p.A4)
MEM File Size (Memory Function)
File size = setting size + data size
Calculation method: "MEM File" ( p.A4)
Recording
length (div)
Data Quantity
Saved Channels
1 2 4 8 16
100 10,001
43 KB 63 KB 103 KB 183 KB 344 KB
1,000 100,001 219 KB 415 KB 806 KB 1.6 MB 3.0 MB
10,000 1,000,001 1.9 MB 3.8 MB 7.7 MB 15 MB 31 MB
100,000 10,000,001 19 MB 38 MB 76 MB - -
REC File Size (Recorder Function)
Filesize = setting size + data size
Calculation method: "REC File" ( p.A4)
Recording
length (div)
Data Quantity
Saved Channels
1 2 4 8 16
100
10,001
63KB 102KB 181KB 340KB 656KB
1,000
100,001 414KB 805KB 1.6MB 3.1MB 6.1MB
10,000
1,000,001 3.8MB 7.7MB 15MB 31MB 61MB
20,000
2,000,001 7.7MB 15MB 31MB 61MB 122MB
