3.5 Input Channel Setting
49
3
Chapter 3 Measurement Procedure
Set the analog channel and logic channel.
3.5 Input Channel Setting
See: "Displaying All Channels for Making the Variable Function Setting" ( p.135)
Pressing [CH.SET] key repeat-
edly displays the various sheets.
[Analog]
[Variable]
[Logic]
No display
Opening the Channel settings window
[WaveCalc]
(When [Wave Calculation] is [On].)
To perform waveform interpolation
Set the waveform display color in the channel setting window to Off.
See: "1. Waveform Display Color" ( p.52)
To make the recording length as long as possible
By limiting the number of channels that are used, more memory can
be allocated to channels using storage memory.
See: "8.4 Setting Channels to Use (Extending the Recording Length)" (
p.127)
To copy the settings of one channel to another
See: "8.9 Copying settings to other channels (calculation No.) (Copy func-
tion)" (
 p.139)
