15.7 Controlling the Instrument with Command Communications (LAN/USB)
284
The following example shows how to make a connection using the telnet software (HyperTerminal)
supplied with Windows XP.
15.7.2 Communication Command Setting
1
Launch HyperTeminal.
Click [Start], [Programs] - [Accessories] - [Com-
munications] - [HyperTerminal], and then click
[HyperTerminal].
The HyperTerminal screen appears.
2
Specify a connection name.
Enter a name in the [Name] field and click the [OK]
button.(You can enter any name.)
A [Connect To] dialog appears.
3
Make the connection settings.
1. In [Connect using] select [TCP/IP (Winsock)].
2. In [Host address], enter the IP address of the
instrument.
3. In [Port number], enter the port number specified
in the [Interface] sheet.
About port numbers
On the instrument, only the most significant 3 digits of the 4-digit
instrument port number are specified.
If you specified "880x" on the instrument, enter "8802" here.
"Command Port (Port number) (LAN only)" (
 p.282)
4. Click the [OK] button.
The connection is made.
Click
Connection
Name
1
2
3
4
