Appendix 1 Default Values for Major Settings
A1
Appendix
Default values for major settings are listed below.
Appendix
Appendix 1 Default Values for Major Settings
Screen Sheet / Window Items Settings
Status
Status
Timebase
Memory 5 μs/div
Recorder 10 ms/div
Sampling (X-Y Recorder) 100 ms/S
Shot 25 div
Format
Memory / Recorder Single
X-Y Recorder X-Y Single
Roll Mode
(Memory)
Auto
Used Ch (Memory) Ch 1-16
Dots-Line (X-Y Recorder) Line
Num Calc. Numerical Calc Off
System
Environment
Grid Doted Line
Time Val Time
Beep Sound Warn
Auto Scal On
File Save
Auto Save Off
Printer
Auto Print Off
Grid Standard
Ch Mark Ch No.
Time Val Time
Mag/Comp Same to display
Copy GUI Yes
Print Area All Wave
Interface
Interface LAN
USB Set USB Memory
Channel
Unit List
Wave_Disp (analog) Color 1 - 16
Wave Density Standard
Wave_Disp (Logic) Off
Logic Width Normal
Range Maximum sensitivity
Coupling DC
Scaling
Disp Ratio
Each channel Off
Comment
Print Comment (Title) Setting
Print Comment (Analog) Setting
Print Comment (Logic) Off
Waveform Trigger settings window
Trigger Mode
Memory Auto
Recorder Single
PreTrigger (Memory) 0%
Trigger Source OR
Timing Start
Trigger for each module Off
Timer Trigger Off
External Trigger Off
