15.3 Accessing the Files on the Instrument From a Computer (Using FTP)
274
The following example shows how to use the IE (Internet Explorer) browser on Windows XP.
Launch IE on the PC and enter "ftp://" plus the IP address of the instrument in
the address bar.
If the IP address of the instrument is "192.168.0.2":
* An authorization user name and password have been set in the System screen
- [Interface] sheet.
See:"15.3.1 Making FTP Settings at the Instrument" ( p.273)
You can also enter the user name and password, delimited by ':' and '@', in front
of the normal IP address.
[ftp:// Username:Password@ instrument IP address]
Example: When the user name is "hioki" and the password is "1234":
Enter [ftp://hioki:1234@192.168.0.2].
15.3.2 Using FTP to Connect to the Instrument
CF Card
Click to display the file stored on the media.
Authorization
required*
Login by entering a user name and
password.
Connect
Login screen
The storage media of the instrument
appear.
authorization
setting
If the connection fails
Check the communications settings of the instrument.
See: " LAN Setup Workflow" ( p.262)
To Next Page
