Appendix 3 About Options
A10
For details of cables and clamps for connecting to the input modules and the instrument, refer to
manual supplied with them.
Items indicated "specify when ordering" are not user-installable. For new pur-
chases, contact your supplier (agent) or nearest Hioki office.
Appendix 3 About Options
Appendix 3.1 Options
Input modules (Measurement amplifiers)
These are installed by insertion into the compartments on the right side of the instrument. Modules can be swapped out as
needed.
Channels
Max Sampling
Rate
A/D
Resolution
Maximum
input voltage
Voltage Measurements
8966 Analog Unit
2 20 MS/s 12 bit 400 VDC
8968 High Resolution Unit 2 1 MS/s 16 bit 400 VDC
RMS Voltage Measurements
8972 DC/RMS Unit 2 1 MS/s 12 bit 400 VDC
Temperature (Thermome-
ter) Measurements
8967 Temp Unit 2 - 16 bit -
Frequency, Count, Pulse
Duty, and Pulse Width Mea-
surements
8970 Freq Unit 2 - 16 bit 400 VDC
For Current Measurement
8971 Current Unit 2 1 MS/s 12 bit -
Strain (Strain Gauge Type
Converter) Measurements
8969 Strain Unit 2 200 kS/s 16 bit 10 VDC
For Digital Signals and
Contact Signal Measurement
8973 Logic Unit 16 20 MS/s - -
See: "17.6 Input Modules Specifications" ( p.304)
Measurement probes, cords, and clamps
Maximum
input voltage
For Voltage Measurement
9197 Connection Cord For high voltage 500 V
L9198 Connection Cord For low voltage 300 V
L9217 Connection Cord Isolated BNC-BNC 300 V
9322 Differential Probe
For high voltage
Following item is required for connec-
tion.
• Voltage measurement with an input
modulerequires the Model 9418-15 AC
Adapter
*
(CAT II)
2000 VDC,
1000 VAC
(CAT III)
600 VAC, DC
9665 10:1 Probe
Maximum rate voltage above
ground is that of the input module.
1 kVrms
(up to 500 kHz)
9666 100:1 Probe
Maximum rate voltage above
ground is that of the input module.
5 kVpeak
(up to 1 MHz)
*: 9418-15 AC Adapter For Model 9322
For Logic Signal Input
9320-01 Logic Probe
Four channels, for detecting voltage and closed/open
contact points
MR9321-01 Logic Probe
Four isolated channels, for detecting AC/DC voltage on/
off (for small terminal types and for lines)
9327 Logic Probe
Four channels, for detecting voltage and closed/open
contact points (high-speed type)
