15.2 Performing Remote Operations on the Instrument (Use an Internet Browser)
266
The following example shows how to use the IE (Internet Explorer) browser on Windows XP.
Launch IE on the PC and enter "http://" plus the IP address of the instrument in the address bar.
If the IP address of the instrument is "192.168.0.2"
*: When user name and password for authentication were set via System screen - [Inter-
face] sheet
See:"15.2.1 Making HTTP Settings on the Instrument" ( p.265)
15.2.2 Connecting to the Instrument With an Internet
Browser
Start/stop measurement ( p.267)
Show remote control screen (
p.268)
Get data from memory of instrument (
p.269)
Get data from CF Card, HDD, or USB memory stick via FTP (
p.270)
Enter a title comment (
p.271)
Enter an analog channel comment (
p.271)
Enter a logic channel comment (
p.271)
Return to the main screen
Login by entering a user name and
password.
Login screen
Operations
No authorization
setting
Authorization
required*
Connect
To Next Page
