13.3 Setting FFT Analysis Conditions
209
13
Chapter 13 FFT Function
Basic measurement configuration settings are performed on the Status screen-[Status] sheet. Measure-
ment configuration can be performed from the Waveform screen
( p.225).
The FFT function can be selected at screens other than the file screen.
13.3 Setting FFT Analysis Conditions
Opening the [Status] sheet
13.3.1 Selecting the FFT Function
Procedure
1
Move the cursor to the function item (the upper most column
of the Settings window).
2
Select [FFT].
