Appendix 3 About Options
A12
Appendix 3.2 Model 9783 Carrying Case
• Observe the following precautions to avoid injury or damage from having the
case fall.
• Do not sit or stand on the case.
• Do not use the casters on unstable, sloping or soft surfaces.
• Be careful to avoid pinched fingers or other accidental injuries when installing
and removing the casters.
• Observe the following precautions to avoid damage to the case.
• Do not exceed the load limit of 15 kg (33 lb).
• Do not open or close the case in the upright position.
• The case includes flammable materials, so do not place it near open flame or
any object hotter than 100°C, as the case could catch fire.
Parts Names
Hinge Stopper
Caster
Latch
See the following procedure to open.
Catch
Butterfly
Manual Storage Compartment
Option Storage Compartment
8847 Instrument Storage Compartment
Carry Bar
To extend, hold down button in
center of carry bar and pull out.
Recording paper, Accessory, etc.
Storage Compartment
Cushioning material
The interior of the carrying case con-
tains cushioning material for protecting
the instrument. Damaged cushioning
material can be repaired for a fee.
Please contact your HIOKI distributor.
Opening the Latch
1
2
Pull the butterfly up, and rotate it 1/2-turn counter-
clockwise.
When the catch releases, pull the butterfly towards
you.
