Chapter 12 Memory Division Function

Memory division function can only be used with the Memory function.

Memory division settings are made on the Status screen - [Memory Div] sheet.

Blocks to be displayed can also be selected on the Waveform screen ( p.115).

Memory Division

Function Chapter 12

Pressing this key repeatedly dis-

plays the various sheets.

[Status]

[Num Calc]

Opening the [Memory Div] sheet

[Wave Calc]

[Memory Div]

When using memory division, the trigger output (TRIG_OUT terminal output) may output the Low

level or output erratically in the following conditions.

• The time axis range is 5 μs/div to 100 μs/div

• The record (measurement) time is 5 ms or less

• Tracking wave display is [OFF].
