17.1 General Specifications
296
Display Section
External Storage
CF Card
Hard Disk Drive (Model 9664 HD Unit: option must be specified when ordering)
USB
External Interfaces
USB
LAN
Modules/Waveform Display
Display character Japanese/English
Display type 10.4-in TFT Color LCD (800 × 600 dots)
Display resolution T-Y waveform display: Normal 25 div (horizontal axis (time axis)) × 20 div (vertical axis (voltage
axis))
X-Y waveform display: Normal 20 div (X axis) × 20 div (Y axis)
Dot pitch 0.264 (Vertical) × 0.264 (Horizontal) mm
Backlight On/Off
Operating life Approx. 50,000 hours
Slots 50 pin 1 slot
Card types CompactFlash
Card Capacity 9726 PC Card 128MB, 9727 PC Card 256MB, 9728 PC Card 512MB,
9729 PC Card 1GB, 9830 PC Card 2G
Data formats FAT, FAT32
Storage contents Setting configurations, Measurement data (binary, text) (data between A-B cursors can be saved),
Screen images (BMP), Printing images (BMP), Calculation results, Thinned storage (simple text)
Storage system 2.5-inch magnetic hard drive
Storage capacity 80 GB
Format FAT32
Storage contents Setting configurations, Measurement data (binary, text) (data between A-B cursors can be saved),
Screen images (BMP), Printing images (BMP), Calculation results, Thinned storage (simple text)
Compliant standards USB2.0compliant
Connector Series-A receptacle: Connecting device: USB memory stick (mass storage device)
Compliant standards USB2.0compliant
Host Connector: Series-A receptacle
Connecting device: USB memory stick (mass storage device)
Function Connector: Series-B receptacle
Connecting device: PC
Functions:mass storage device (for file transfer from internal hard drive to PC)
Communications support (PC-controlled)
Compliant standards IEEE802.3 Ethernet 100BASE-TX DHCP-compliant, DNS-compliant, FTP server, HTTP server
Connector RJ-45
Measurement mode Module model-dependent
Measurement range Module model-dependent
Input coupling Module model-dependent
Low-pass filter Module model-dependent
Attenuating probe compensa-
tion
Included (Auto-scaling for different attenuating probes)
Displayed graphs On-screen settings for displayed graphs and multi-graph printing (up to 8 graphs)
Waveform display Select Off, or from 16 colors
Printing density Four levels
Waveform display position 1% gradients, preset (select from ascending order, descending order, 0%, or 50%)
Zero adjust All channels and ranges together
