Hioki 8847 - Setting the Print Concentration of the Waveform

6.4 Setting the Print Concentration of the Waveform
94
The printing concentration of the waveform can be set for each channel.
6.4 Setting the Print Concentration of the Wave-
form
Procedure
To open the screen: Press the CHAN key → [Unit List] sheet, or [Each Ch] sheet
[Unit List] sheet
[Each Ch] sheet
Move the cursor to the [Wave], or [Wave_Disp].
Select
Light, Midlight Standard (default setting), Middark,
Dark
When the waveform print concentration is Light, a temporary drop in power volt-
age (for example, a momentary power failure) during printing may cause the
print to jump.
