255

Chapter 14 System Environment Settings

Use the System screen - [Environment] sheet to make system-related settings.

System Environment

Settings Chapter 14

Pressing this key repeatedly

displays the various sheets.

See: "Chapter 16 External Control" ( p.287)

Opening the [Environment] sheet

[Environment]

[File Save]

[Printer]

[Init]

[Interface]
