1.3 Screen Organization
12
The screen configuration is as listed below. The display appears when a key is pressed.
On the Waveform screen, the trigger settings window and channel settings window can be brought
up.
1.3 Screen Organization
Waveform Screen
This screen serves for observing the waveform.
The settings window at the right shows the measurement parameters.
Trigger settings window/Channel settings window
Shows details about the trigger settings.
Shows details about the analog channel and logic channel settings.
Status Screen
This screen serves for making settings for the measurement method and the numerical
calculation of waveform data.
Each push of the STATUS key toggles between the following two sheets.
• [Status] sheet
• [Num Calc] sheet
• [Memory Div] sheet
• [Wave Calc] sheet
Channel Screen
This screen serves for making channel settings, scaling settings, and comment settings.
Each push of the CHAN key cycles through the following sheets.
• [Unit List] sheet
• [Each Ch] sheet
• [Scaling] sheet
• [Comment] sheet
System Screen
This screen serves for making environment settings, saving and printing files, making
interface settings, and for performing data initialization.
Each push of the SYSTEM key cycles through the following sheets.
• [Environment] sheet
• [File Save] sheet
• [Printer] sheet
• [Interface] sheet
• [Init] sheet
File Screen
This screen serves for viewing data files saved on media (CompactFlash cards, hard disk
drive, USB memory stick, internal memory).
