Hioki 8847 - Chapter 16 External Control; Opening the [Environment] sheet

15.5 Wave Viewer (Wv)
277
12
Chapter 15 Connection to a Computer
15
The viewer has a CSV conversion function. Converted files may be read by a spreadsheet program.
This section explains how to install and uninstall and how to start and quit the
Wave Viewer.
System requirements
For a PC running Windows 95, 98, Me, Windows NT4.0 SP3 or later, Windows
2000, or Windows XP
1. When you insert the Application Disk (CD-R) into the CD-ROM drive, the open-
ing page should appear automatically.
If it does not appear, open the "index.htm" file with your Web browser.
2. Select the language to display (click the English icon).
3. Click the [Wave viewer (Wv)] icon to view Wv specifications and revision his-
tory.
4. Click the [Install] icon at the top right of the page to open the [File Download]
dialog.
5. Click [Open] to display the confirmation dialog to proceed with installation. And
go on the procedure.
6. Click [Next] to open the installation destination selection window.
Click the [Browse] button to change the installation folder.
7. Click [Next] to start installation.
The program is now installed.
Before using the program, review the "READ ME" text file.
In the Windows Start menu, select [Programs] - [HIOKI] - [Wv.] This starts the
Wave Viewer application.
Access the menus of the Wave Viewer application and select [File] - [Exit] to
shut down the program. Alternatively, you can click the Close button at the top
right of the screen.
1. From the Windows Start button, open the [control panel] and click on [Add or
remove programs].
2. Select [HIOKI Wave Viewer (Wv)] and uninstall the application.
To upgrade to a newer version, uninstall the old version first and then install the
new version.
15.5 Wave Viewer (Wv)
Installation (Windows XP)
Startup
Shutdown
Uninstallation
